Statistics of station Windeck

Here you can find statistics of the TOA lightning detection station Windeck.

  • Id: 3025
  • Firmware: 0.0
  • Controller: 19.5
  • Amplifier: H1 / E1
  • Antenna 1+2+3: Ferrite rod, length=200mm, diameter=12mm
  • Antenna 4: Electric field, length=100mm
  • Comment: Test Station for antennas
  • Other Stations from this User: 2956, 3097, 3120, 3131

General statistics of the last hour

  • Station active: yes
  • Last update: 6.8 minutes ago
  • Last detected stroke: 2025-06-16 04:36:25
  • Strokes: 95
  • Signals: 10,992
  • Locating ratio: 0.9%
  • Stroke ratio: 4.2%
  • Strokes station min participants (13-18 stations): 0 (0.0%)

Surrounding area

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Windeck and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Windeck and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
