Hint: Statistics of station Newcastle are displayed. Takaisin asemalle Hertfordshire, U.K.

Newcastle tilastot

Here you can find statistics of the TOA lightning detection station Newcastle.

  • ID: 1645
  • Firmware: 0.0
  • Controller: 19.3
  • Amplifier: H0 / E0
  • Antenni 1: Electric field, length=10mm
  • Antenni 2+3: Ferrite rod, length=200mm
  • Antenni 4: Coaxial loop, diameter=1000mm, shielded
  • Comment: H1-NE/SW, H2-NW/SE, H3-N/S in loft, E1-15m above ground

General statistics of the last hour

  • Asema aktiivinen: yes
  • Last update: noin 3.2 minuuttia sitten
  • Viimeisin havaittu salamanisku: 2025-04-29 21:56:47
  • Salamaniskut: 7
  • Signaalit: 245
  • Paikannussuhde: 2.9%
  • Iskusuhde: 1.7%
  • Strokes station min participants (14-19 Asemat): 0 (0.0%)

Surrounding area

Salamaniskujen tiheys

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Newcastle and the mean stroke count for all stations

Graafit: Salamastatistiikka

Signaalien tiheys

The count of received signals per hour of the station Newcastle and also mean value of all stations.

Graafit: Signaalistatistiikka

Suhteet

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graafit: Paikannus- ja iskusuhteet

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graafit: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graafit: Salamaniskujen suhde suuntaan
