Hint: Statistics of station Bismarck are displayed. Takaisin asemalle Hertfordshire, U.K.

Bismarck tilastot

Here you can find statistics of the TOA lightning detection station Bismarck.

  • ID: 1002
  • Firmware: 1.6
  • Controller: 10.4
  • Amplifier: 12.3 / 13.1
  • Antenni 1+2: Ferrite rod, length=284mm, shielded
  • Antenni 4+5: Electric field, length=370mm
  • Website: www.bismarckweather.net
  • Comment: 280mm x 7.5mm ferrite, E-Field

General statistics of the last hour

  • Asema aktiivinen: yes / Ei vastaanottoa
  • Last update: noin 3.2 minuuttia sitten
  • Viimeisin havaittu salamanisku: None
  • Salamaniskut: 0
  • Signaalit: 0
  • Paikannussuhde: -
  • Iskusuhde: 0.0%
  • Strokes station min participants (14-19 Asemat): 0 (0.0%)

Surrounding area

Salamaniskujen tiheys

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Bismarck and the mean stroke count for all stations

Graafit: Salamastatistiikka

Signaalien tiheys

The count of received signals per hour of the station Bismarck and also mean value of all stations.

Graafit: Signaalistatistiikka

Suhteet

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graafit: Paikannus- ja iskusuhteet

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graafit: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graafit: Salamaniskujen suhde suuntaan
