Statistics of station Ittigen HB9CJQ RED

Here you can find statistics of the TOA lightning detection station Ittigen HB9CJQ RED.

  • Id: 786
  • Firmware: 1.6
  • Controller: 10.3
  • Amplifier: 12.3
  • Antenna 1+2+4+5: Ferrite rod, length=200mm, shielded
  • Comment: Projektgruppe HB9F, Bern
  • Other Stations from this User: 2106

General statistics of the last hour

  • Station active: yes / no reception
  • Last update: 9.7 minutes ago
  • Last detected stroke: None
  • Strokes: 0
  • Signals: 0
  • Locating ratio: -
  • Stroke ratio: 0.0%
  • Strokes station min participants (13-18 stations): 0 (0.0%)

Surrounding area

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Ittigen HB9CJQ RED and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Ittigen HB9CJQ RED and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
